Performance Specifications
The specifications of the NX-series EtherNet/IP Unit are given below.
Item
NX-EIP201
Ether-
Net/IP
port
Number of ports 2
Physical layer 10BASE-T, 100BASE-TX, or
1000BASE-T
Frame length 1,514 bytes max.
Media access method CSMA/CD
Modulation Baseband
Topology Star
Baud rate 1 Gbps (1000BASE-T) max.
Transmission media STP (shielded, twisted-pair)
cable of Ethernet category 5,
5e or higher
Maximum transmission distance between Ethernet switch and
node
100 m
Maximum number of cascade connections There are no restrictions if an
Ethernet switch is used.
LLDP Supported.
BOOTP client Supported.
DHCP client Not supported.
DNS client Supported.
SNMP agent, traps Supported.
CIP service:
T
ag data links
(cyclic commu-
nications)
Maximum number of connections 256 per port
512 total
Packet interval
*1*2
Can be set for each connec-
tion.
1.0 to 10,000 ms in 1.0-ms in-
crements
Allowed communications bandwidth per Unit
40,000 pps
*3*4
(including
heartbeat)
Maximum number of tag sets 256 per port
512 total
T
ag types Network variables
Number of tags per connection (i.e., per tag
set)
64 (63 tags if Controller sta-
tus is included in the tag set.)
Maximum number of tags 1,024 per port
2,048 total
Maximum link data size per node (total size for
all tags)
793,328 bytes
Maximum data size per connection 1,444 bytes
Maximum number of registrable tag sets 256 per port
512 total
(1 connection = 1 tag set)
Maximum tag set size 1,444 bytes (Two bytes are
used if Controller status is in-
cluded in the tag set.)
Multicast packet filter
*5
Supported.
