Sysmac Studio Settings for the

EtherNet/IP Port

This section describes the EtherNet/IP port settings with the Sysmac Studio.

The EtherNet/IP port settings are made for each NX-series EtherNet/IP Unit that is

connected to the CPU Unit on the Sysmac Studio. Make the EtherNet/IP port settings

on the Sysmac Studio under Configurations and Setup

- CPU/Expansion Racks -

CPU Rack: X Bus - Unit No.: NX-EIP201 () - EtherNet/IP Port Settings.

7-1 TCP/IP Settings Display................................................................................. 7-2

7-2 LINK Settings Display.................................................................................. 7-10

7-3 SNMP Settings Display................................................................................ 7-11

7-4 SNMP Trap Settings Display ....................................................................... 7-13

7-5 CIP Settings Display .................................................................................... 7-15

7-1

NX-series EtherNet/IP Unit User's Manual (W627)
