3 Registering tags and tag sets --- Refer to Registering the Tag
and T
ag Set on page A-14.
EtherNet/IP Connection Set-
tings (Tag Set Display)
↓ Register the network variables that are set in step 2 as
tags and tag sets.
4 Setting connections --- Refer to Setting Connections
for the Originator Device on
page A-17.
EtherNet/IP Connection Set-
tings (Connection Display)
↓ Specify devices (i.e., target devices and originator devi-
ces) and tag sets to communicate with using the Ether-
Net/IP connections.
5 Going online from the Sysmac Studio ---
Refer to Transferring the
Connection Settings Data on
page A-28
.
• Main Window
↓
6 Downloading EtherNet/IP connection
settings
--- Refer to Transferring the
Connection Settings Data on
page
A-28.
• Synchronization Window/
Transfer to Controller Dia-
log Box
• EtherNet/IP Connection
Settings
Note Connections automatically start after
the download.
↓
7 Checking operation ---
Refer to A-3-5 Checking
Communications Status with
the Sysmac Studio and Trou-
bleshooting on page A-32
.
EtherNet/IP Connection Moni-
tor Tab Page
Stopping and starting connections
*1. Variables with its Network Publish attribute set to Output or Input in the Global Variable T
able are called
network variables.
A-3-3
EtherNet/IP Connection Settings
This section describes the screen configuration for EtherNet/IP connection settings.
Screen Transitions in the EtherNet/IP Connection Settings
• Connection Settings
Select EtherNet/IP Connection Settings from the Tools Menu.
Double-click or right-click the
device to set and select Edit
from the menu.
EtherNet/IP Connection Settings (Tag Set Display)
Use the tab icons to switch
between displays.
EtherNet/IP Connection Settings
(Connection Display)
Right-click the device to set
and select Monitor from the
menu.
EtherNet/IP Device List Tab Page
EtherNet/IP Connection Monitor Tab Page
Appendices
A-8
NX-series EtherNet/IP Unit User's Manual (W627)

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
