7-4
SNMP Trap Settings Display
l
SNMP Trap
Setting Description Default
SNMP trap Specify whether to use the SNMP trap (network error detec-
tion).
*1
If the Do not use Option is selected for SNMP trap, SNMP traps
are not sent to the SNMP manager
Do not use
Port No.
*2
Set the port number to use to connect to the SNMP server.
It is normally not necessary to change this setting.
162
*1. If you specify to use the SNMP trap, you also have to set Trap 1 and Trap 2 as described below.
*2. The following ports are used by the system and cannot be set by the user: 25, 53, 68, 110, 2222, 2223,
2224, 9600, and 44818.
Additional Information
Refer to 11-1-1 Overview on page 11-2 for details on the SNMP trap.
l
Trap 1
If the Use Option is selected for SNMP trap, you need to make the following settings.
Setting Description Default
Specifying method Set the specifying method for the SNMP manager destination for
SNMP traps.
• IP address
• Host name
IP address
IP address Set the IP address of the SNMP manager.
(Set this setting if the Specifying method in the Trap 1 settings
is set to the
IP address Option.)
None
7 Sysmac Studio Settings for the EtherNet/IP Port
7-13
NX-series EtherNet/IP Unit User's Manual (W627)
7-4 SNMP Trap Settings Display
