Omron NX Series User Manual

A-3
Use the Sysmac Studio to Set the Tag
Data Links (EtherNet/IP Connections)
A-3-1
Overview of the Tag Data Links (EtherNet/IP Connections) Set-
tings with the Sysmac Studio
You can use the Sysmac Studio to set the settings required for creating tag data links (EtherNet/IP
connections)*1 on the NX-series EtherNet/IP Units.
*1. The tag data links and EtherNet/IP connections enable cyclic tag data exchanges on an EtherNet/IP network
between Controllers or between Controllers and other devices. Here, "EtherNet/IP connection" refers to both
the tag data links and the EtherNet/IP connections.
Acceptable System Configuration Conditions for Setting the Ether-
Net/IP Connection Settings on the Sysmac Studio
If an NX-series EtherNet/IP Unit operates as the originator device, you can use the Sysmac Studio to
set the originator device settings for the EtherNet/IP connections.
Similarly, if an NX-series EtherNet/IP Unit operates as the target device, you can use the Sysmac Stu-
dio to set the tags and tag sets of the target device.
Appendices
A-6
NX-series EtherNet/IP Unit User's Manual (W627)
