Omron NX Series User Manual

Item
Built-in
Ether-
Net/IP
port on
NX701
CPU
Unit
Built-in
Ether-
Net/IP
port on
NX502
CPU
Unit
Built-in
Ether-
Net/IP
port on
NX102
CPU
Unit
Built-in
Ether-
Net/IP
port on
NX1P2
CPU
Unit
Built-in
Ether-
Net/IP
port on
NJ-ser-
ies
CPU
Unit
NX-ser-
ies
Ether-
Net/IP
Unit
CJ-ser-
ies
Ether-
net
Unit
EtherNet/IP Unit (built-in
port on CJ2 CPU Unit)
Unit
version
1.0
Unit
version
2.0
Unit
version
2.1
Connection set-
tings using the
Sysmac Studio
OK OK OK OK OK OK
--- --- ---
OK
*1. This is equivalent to the event log in the EtherNet/IP of an NJ-series Controller.
*2. You cannot use the following functions if you connect to the CPU Unit through an EtherNet/IP Unit.
• Placing the Sysmac Studio online with the CPU Unit (However, you can place the Network Configurator online)
• Using the T
roubleshooter of an NS-series PT
Appendices
A-5
NX-series EtherNet/IP Unit User's Manual (W627)
A-2 Functional Comparison of EtherNet/IP Ports on NJ/NX-series CPU Units and Other Series
A

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
