CIP Settings Display
l
CIP Message Server
Setting Description Default
CIP Message Server Specify whether to use the CIP message server or not.
If the Use Option is selected, the following ports will be opened.
• UDP 2222
• UDP 44818
• TCP 44818
Use
Refer to 10-3 Server Function of CIP Message Communications on page 10-23 for restrictions
when the
Do not use Option is selected for CIP message server.
l
QoS
Setting Description Default
Prioritize CIP Safety
communication
Select whether to prioritize CIP Safety communications in QoS. Do not use
