Omron NX Series User Manual

7-3
SNMP Settings Display
l
SNMP
Setting Description Default
SNMP service
Specify whether to use the SNMP monitor service.
*1
If the Do not use Option is selected, an SNMP manager cannot
connect from an external device.
Do not use
Port No.
*2
Set the port number to use to connect to the SNMP server that is
used to connect from an SNMP manager
.
This setting does not normally need to be changed.
161
Address Set the communications device administrator
’s name and instal-
lation location as text information. You do not necessarily have to
input all items. This information is read by the SNMP manager
.
(You can input up to 255 single-byte alphanumeric characters for
each item.)
None
Location None
Send a recognition
trap
Set whether to send an authentication trap.
If you select Send a recognition trap and there is access from
an SNMP manager that is not set in Recognition 1 or Recognition
2, an authentication trap is sent to the SNMP manager.
If you select
Send a recognition trap, specify the SNMP trap
settings on the SNMP Trap Tab.
Not selected
*1. If you select the Use Option for the SNMP service, you also have to set Recognition 1 and 2 as descri-
bed below.
*2. The following ports are used by the system and cannot be set by the user: 25, 53, 68, 110, 2222, 2223,
2224, 9600, and 44818.
Additional Information
Refer to Section 11 SNMP Agent on page 11-1 for details on the SNMP service.
7 Sysmac Studio Settings for the EtherNet/IP Port
7-11
NX-series EtherNet/IP Unit User's Manual (W627)
7-3 SNMP Settings Display
7
