Variable name EIP_Comm1Status.TargetNodeErr[255]
Meaning CIP Communications1 Target Node Error Infor-
mation
Global/local Global
Function Indicates that the connection for the Registered Target Node Information for CIP communications 1 was not es-
tablished or that an error occurred in the target Controller
.
The array elements are valid only when the Registered T
arget Node Information is TRUE.
Array[x] is TRUE: A connection was not normally established with the target node for a target node ID of x (the
Registered Target Node Information is TRUE and the Normal Target Node Information is FALSE), or a connection
was established with the target node but an error occurred in the target Controller.
Array[x] is FALSE: The target node is not registered for a target node ID of x (the Registered Target Node Infor-
mation is FALSE), or a connection was normally established with the target node (the Registered Target Node
Information is TRUE and the Normal Target Node Information is TRUE). An error occurred in the target Controller
(the Target PLC Error Information is TRUE).
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm2Status.TargetNodeErr[255]
Meaning CIP Communications2 Target Node Error Infor-
mation
Global/local Global
Function Indicates that the connection for the Registered Target Node Information for CIP communications 2 was not es-
tablished or that an error occurred in the target Controller
.
The array elements are valid only when the Registered T
arget Node Information is TRUE.
Array[x] is TRUE: A connection was not normally established with the target node for a target node ID of x (the
Registered Target Node Information is TRUE and the Normal Target Node Information is FALSE), or a connection
was established with the target node but an error occurred in the target Controller.
Array[x] is FALSE: The target node is not registered for a target node ID of x (the Registered Target Node Infor-
mation is FALSE), or a connection was normally established with the target node (the Registered Target Node
Information is TRUE and the Normal Target Node Information is TRUE). An error occurred in the target Controller
(the Target PLC Error Information is TRUE).
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-28
NX-series EtherNet/IP Unit User's Manual (W627)
