Variable name EIP_Comm2Status.TargetPLCModeSta[255]
Meaning CIP Communications2 Target PLC Operating
Mode
Global/local Global
Function Shows the operating status of the target node Controllers that are connected for CIP communications 2, with the
EtherNet/IP port as the originator
.
The array elements are valid only when the corresponding Normal Target Node Information is TRUE. If the corre-
sponding Normal T
arget Node Information is FALSE, it indicates the previous operating status.
Array[x] is TRUE: This is the operating state of the target Controller with a node address of x.
Array[x] is FALSE: Other than the above.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm1Status.TargetPLCErr[255]
Meaning CIP Communications1 Target PLC Error Infor-
mation
Global/local Global
Function Shows the error status (logical OR of fatal and non-fatal errors) of the target node Controllers that are connected
for CIP communications 1, with the EtherNet/IP ports as the originator
. The array elements are valid only when
the corresponding Normal T
arget Node Information is TRUE. The immediately preceding value is retained if this
variable is FALSE.
Array[x] is TRUE: A fatal or non-fatal error occurred in the target Controller with a target node ID of x.
Array[x] is FALSE: Other than the above.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm2Status.TargetPLCErr[255]
Meaning CIP Communications2 Target PLC Error Infor-
mation
Global/local Global
Function Shows the error status (logical OR of fatal and non-fatal errors) of the target node Controllers that are connected
for CIP communications 2, with the EtherNet/IP ports as the originator
. The array elements are valid only when
the corresponding Normal T
arget Node Information is TRUE. The immediately preceding value is retained if this
variable is FALSE.
Array[x] is TRUE: A fatal or non-fatal error occurred in the target Controller with a target node ID of x.
Array[x] is FALSE: Other than the above.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-27
NX-series EtherNet/IP Unit User's Manual (W627)
6-3 Specifications for Individual Device Variables
