Variable name EIP_Comm2Status.RegTargetSta[255]
Meaning CIP Communications2 Registered Target Node
Information
Global/local Global
Function Gives a list of nodes for which EtherNet/IP connections are registered for CIP communications 2.
This variable is valid only when the EtherNet/IP port is the originator
.
Array[x] is TRUE: The connection to the node with a target node ID of x is registered.
Array[x] is F
ALSE: The connection to the node with a target node ID of x is not registered.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm1Status.EstbTargetSta[255]
Meaning CIP Communications1 Normal Target Node In-
formation
Global/local Global
Function Gives a list of nodes that have normally established EtherNet/IP connections for CIP communications 1.
Array[x] is TRUE: The connection to the node with a target node ID of x was established normally
.
Array[x] is F
ALSE: The connection to the node with a target node ID of x was not established, or an error occur-
red.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm2Status.EstbTargetSta[255]
Meaning CIP Communications2 Normal Target Node In-
formation
Global/local Global
Function Gives a list of nodes that have normally established EtherNet/IP connections for CIP communications 2.
Array[x] is TRUE: The connection to the node with a target node ID of x was established normally
.
Array[x] is F
ALSE: The connection to the node with a target node ID of x was not established, or an error occur-
red.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm1Status.TargetPLCModeSta[255]
Meaning CIP Communications1 Target PLC Operating
Mode
Global/local Global
Function Shows the operating status of the target node Controllers that are connected for CIP communications 1, with the
EtherNet/IP port as the originator.
The array elements are valid only when the corresponding Normal Target Node Information is TRUE. If the corre-
sponding Normal T
arget Node Information is FALSE, it indicates the previous operating status.
Array[x] is TRUE: This is the operating state of the target Controller with a node address of x.
Array[x] is FALSE: Other than the above.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-26
NX-series EtherNet/IP Unit User's Manual (W627)
