Variable name EIP_Comm2Status.TDLinkRunSta
Meaning CIP Communications2 Tag Data Link Communi-
cations Status
Global/local Global
Function Indicates that at least one connection is in normal operation in CIP communications 2.
TRUE: Normal operation
F
ALSE: Other than the above.
Data type BOOL Range of values TRUE or F
ALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm1Status.TDLinkAllRunSta
Meaning CIP Communications1 All Tag Data Link Com-
munications Status
Global/local Global
Function Indicates that all tag data links are communicating in CIP communications 1.
TRUE: T
ag data links are communicating in all connections as the originator.
F
ALSE: An error occurred in at least one connection.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm2Status.TDLinkAllRunSta
Meaning CIP Communications2 All Tag Data Link Com-
munications Status
Global/local Global
Function Indicates that all tag data links are communicating in CIP communications 2.
TRUE: T
ag data links are communicating in all connections as the originator.
F
ALSE: An error occurred in at least one connection.
Data type BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
Variable name EIP_Comm1Status.RegTargetSta[255]
Meaning CIP Communications1 Registered Target Node
Information
Global/local Global
Function Gives a list of nodes for which EtherNet/IP connections are registered for CIP communications 1.
This variable is valid only when the EtherNet/IP port is the originator.
Array[x] is TRUE: The connection to the node with a target node ID of x is registered.
Array[x] is F
ALSE: The connection to the node with a target node ID of x is not registered.
Data type ARRAY [0..255] OF BOOL Range of values TRUE or FALSE
R/W access R Retained Not retained. Network Publish Do not publish.
Usage in user pro-
gram
Possible. Related in-
structions
---
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-25
NX-series EtherNet/IP Unit User's Manual (W627)
6-3 Specifications for Individual Device Variables
