3 Click the Open Button to read out the network configuration file.
4 The Network Configurator's Title Bar will display the name of the file that was read out.
5 Select options in the Option Area as necessary.
The options are listed below
.
Setting Description
Select target network Allows you to select specific networks from the network configura-
tion and open them.
Add to current document Allows you to add the networks from the network configuration file
that is currently open to the current configuration file.
Additional Information
The save format will depend on the version of the Network Configurator. You can import config-
uration files (*.ncf) created with the Network Configurator for EtherNet/IP (version 2 or lower) if
you select External Data -
Import from the File Menu.
9 Tag Data Link Functions
9-68
NX-series EtherNet/IP Unit User's Manual (W627)
