General
Status
(hex)
Additional
Status
(hex)
Description
01 0114 Either the vendor ID or the product code in the key segment does not match
the device.
01 0115 Device type in the key segment does not match the device.
01 0116 Major Revision or Minor Revision in the key segment.
01 0117 Invalid connection point.
01 0118 Invalid configuration format.
01 0119 Connection request failed because there is no controlling connection currently
open.
01 011A Target application cannot support any more connections.
01 011B RPI is smaller than the production inhibit time.
01 0203 Connection cannot be closed because the connection has timed out.
01 0204 Unconnected_Send service timed out while waiting for a response.
01 0205 Parameter error in Unconnected_Send service.
01 0206 Message too large for unconnected message service.
01 0207 Unconnected acknowledgment without reply.
01 0301 No buffer memory available.
01 0302 Network bandwidth not available for data.
01 0303 No tag filters available.
01 0304 Not configured to send real-time data.
01 0311 Port that was specified in port segment is not available.
01 0312 Link address that was specified in port segment is not available.
01 0315 Invalid segment type or segment value in path.
01 0316 Path and connection were not equal when closing the connection.
01 0317 The segment is not present. Or, the encoded value in the network segment is
invalid.
01 0318 Link address to self is invalid.
01 0319 Resources on secondary are unavailable.
01 031A Connection is already established.
01 031B Direct connection is already established.
01 031C Others
01 031D Redundant connection mismatch.
01 031E There are no more reception resources available on the sending module.
01 031F No connection resources exist for the target path.
01 0320-07FF Vendor specific.
10 CIP Message Communications
10-22
NX-series EtherNet/IP Unit User's Manual (W627)
