Instance ID
Specify 00 or 01 hex.
Attribute ID
The attribute ID specifies the information to read.
l
Class Attribute ID
The class attribute ID specifies the attribute of the entire object.
Attribute ID Parameter name Description
Attrib-
ute
Read data
Data
type
Value
01 hex Revision Revision of the object Read UINT 0001 hex
02 hex Max Instance The maximum instance num-
ber
Read UINT 0001 hex
l
Instance Attribute ID
The instance attribute ID specifies the attribute of the instance.
Attribute ID Parameter name Description Attribute
Read data
Data
type
Value
01 hex Vendor ID Vendor ID Read UINT 002F hex
02 hex Device Type Device type Read UINT 000C hex
03 hex Product Code Product code Read UINT Refer to (1) Product Codes
for Each Model, below
.
04 hex
Revision Device revision Read Struct ---
Major Revision Major revision Read USINT Refer to (2) Major and Minor
CIP Revisions, below.
Minor Revision
Minor revision Read USINT
05 hex Status Status of the EtherNet/IP
port
Read WORD Refer to (3) Status Details of
the Built-in EtherNet/IP Port,
below.
06 hex
Serial Number Serial number Read UDINT Set value
07 hex Product Name Product name Read STRIN
G
Set value
1. Product Codes for Each Model
Model Product Code
NX701-££££
067D hex
NX502-1300 0BF5 hex
NX502-1400 0BF6 hex
NX502-1500 0BF7 hex
NX-EIP201 0BF4 hex
NX102-1200 0BBB hex
NX102-1100 0BBA hex
NX102-1000 0BB9 hex
10 CIP Message Communications
10-29
NX-series EtherNet/IP Unit User's Manual (W627)
10-5 CIP Object Services
10
10-5-2 Identity Object (Class ID: 01 hex)
