Name Standard [(identifier) attribute] Support
Implementation spec-
ifications
tcpCurrEstab [(9) RO]
The total number of TCP connections cur-
rently in the ESTABLISHED or the CLOSE-
W
AIT state.
Support-
ed
According to the stand-
ard.
tcpInSegs [(10) RO]
The total number of received segments. This
includes the number of error segments.
Support-
ed
According to the stand-
ard.
tcpOutSegs [(11) RO]
The total number of sent segments. This in-
cludes the number of segments for the cur-
rent connection, but does not include the
number of segments for resent data only.
Support-
ed
According to the stand-
ard.
tcpRetransSegs
[(12) RO]
The total number of resent segments.
Support-
ed
According to the stand-
ard.
tcpConnTable [(13) NA]
The information table specific to the TCP
connection.
--- ---
tcpConnEntry [(1) NA]
Entry information related to a specific TCP
connection. This value is deleted if the con-
nection changes to the CLOSE state. The in-
dices are tcpConnLocalAddress,
tcpConnLocalPort, tcpConnRemAddress,
and tcpConnRemPort.
--- ---
tcpConnState [(1) RW]
The status of the TCP connection.
closed (1)
listen (2)
synSent (3)
synReceived (4)
established (5)
finW
ait1 (6)
finW
ait2 (7)
closeWait (8)
lastAck (9)
closing (10)
timeWait (11)
Support-
ed
According to the stand-
ard.
tcpConnLoca-
lAddress
[(2) RO]
The local IP address of this TCP connection.
A value of 0.0.0.0 is used for connections in
the LISTEN state that accept connections
from any IP interface related to the node.
Support-
ed
According to the stand-
ard.
tcpConnLocal-
Port
[(3) RO]
The local port number for this TCP connec-
tion.
Support-
ed
According to the stand-
ard.
tcpConnRe-
mAddress
[(4) RO]
The remote IP address for this TCP connec-
tion.
Support-
ed
According to the stand-
ard.
tcpConnRem-
Port
[(5) RO]
The remote port number for this TCP connec-
tion.
Support-
ed
According to the stand-
ard.
11 SNMP Agent
11-16
NX-series EtherNet/IP Unit User's Manual (W627)
