Event name Tag Data Link Setting Error Event code 34200000 hex
Meaning An error was detected in the communications settings for tag data links.
Source X Bus EtherNet/IP Function Mod-
ule
Source details 1 to 4: Mounting
position of the X
Bus Unit (unit
number)
and
CIP1/CIP2
are
given in combi-
nation
Detection tim-
ing
At power ON or
Controller reset
Error attributes Level Minor fault Recovery Automatic re-
covery (after
downloading the
tag data link set-
tings), cycle the
power supply, or
Controller reset
Log category System
Effects User program Continues. Operation T
ag data link communications are not possible.
Indicators EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
Flashes at 1-s intervals. Flashes at 1-s intervals. ---
Device variable Variable Data type Name
EIP_Comm1Status.TDLinkCfgErr BOOL CIP Communications1 Tag Data
Link Setting Error
EIP_Comm2Status.TDLinkCfgErr BOOL CIP Communications2 Tag Data
Link Setting Error
Cause and cor-
rection
Assumed cause Correction Prevention
Power was interrupted when a
download was in progress for the
tag data link settings.
Please perform one of the follow-
ing corrections.
• Execute Clear All Memory oper-
ation.
• Download the tag data link set-
tings.
• Clear the tag data link settings.
Do not turn OFF the power supply
to the Controller while downloading
the tag data link settings.
Memory error If the above measures do not work,
replace the CPU Unit.
None
Attached infor-
mation
Attached information 1: Error type
01 hex: Non-volatile Memory Access Error
, 02 hex: There is an inconsistency in the set values.
Precautions/
Remarks
None
14 Troubleshooting
14-33
NX-series EtherNet/IP Unit User's Manual (W627)
14-4 Checking with the Sysmac Studio, an HMI, and Instructions That Read Error
Status
14
14-4-4 Error Details
