Installation Height
120
Approx. 150 to 175
(Unit: mm)
The dimension from the back of the Unit to the communications cable varies depending on the cable
connector
. Use the following dimensions as a guide.
Cable connector
Dimension from the back of the Unit to the cable
Manufacturer
Model
Panduit Corporation
MPS588-C
Approx. 150 mm
OMRON
XS6G-T421-1
Approx. 175 mm
Appendices
A-3
NX-series EtherNet/IP Unit User's Manual (W627)
A-1 Dimensions
A
402
404
