Name Description
Originator list (in the Output
Tag Set
Tab Page), Target list
(in the Input Tag Set Tab
Page)
Gives the detailed information of the connected originators.
Originator name (in the
Output Tag Set T
ab Page),
or Target name (in the
Input Tag Set Tab Page)
Gives no information.
IP address (in the Output
Tag Set
Tab Page), or Re-
mote IP address (in the
Input Tag Set Tab Page)
Gives the IP addresses allocated for the originators.
Connected time (in the
Output Tag Set T
ab Page)
Gives the total duration of connection with the originator in milliseconds.
Unconnected time (in the
Output Tag Set T
ab Page)
Gives the total duration of disconnection with the originator in milliseconds.
Destination IP address (in
the Output Tag Set T
ab
Page)
Gives the destination IP addresses. If the multi-cast connections are used,
its own multi-cast address is displayed.
O->T RPI (packet interval) Gives the RPI of connection from the originator to the target in milliseconds.
T->O Heartbeat transmis-
sion cycle (ms)
Gives the heartbeat transmission period of the connections from the target
to the originator in milliseconds.
O->T Timeout Gives the timeout time for the connections from the originator to the target
in milliseconds.
T->O Timeout Gives the timeout time for the connections from the target to the originator
in milliseconds.
O -> T API (actual packet
interval)
Gives the RPI of connection from the originator to the target in milliseconds.
T->O Actual heartbeat
transmission cycle (ms)
Gives the actual heartbeat transmission period of the connections from the
target to the originator in milliseconds.
O->T Connection ID Gives the connection identification for the connections from the originator to
the target in hexadecimal.
T->O Connection ID Gives the connection identification for the connections from the target to the
originator in hexadecimal.
• Ethernet Information T
ab Page
This tab page displays the communications status at the communications driver level of the Ether-
net/IP port.
The error counter information can be used to confirm whether communications problems have oc-
curred.
Under the Tag Data Link, you can confirm characteristics such as the bandwidth usage (PPS).
Appendices
A-36
NX-series EtherNet/IP Unit User's Manual (W627)
