• Check the EtherNet/IP port indicators.
• Use the Sysmac Studio to check the communications status
with the All Tag Data Link Communications Status device var-
iable.
• Use the monitor function of the Network Configurator to con-
firm that the tag data links are in normal operation.
l
Using the Message Communications Service
•
CIP Communications Instructions
1
Execute CIP communications instructions in the user program. Section 10 CIP Message Com-
munications on page 10-1
↓
2
Check operation. S
ection 3 Part Names and Func-
tions on page 3-1
S
ection 14 Troubleshooting on
page 14-1
• Use the Sysmac Studio to check the communications status
with the end codes of the instructions (Done, Err, and ErrID).
l
Using the SNMP Agent
1
Use the Sysmac Studio to set the initial settings of the Ether-
Net/IP Function Module.
Section 11 SNMP Agent on page
1
1-1
• Set the SNMP settings.
• Set the SNMP trap settings.
↓
2
Check operation.
• Check the event log to see if the SNMP agent started.
l
Using the BOOTP
1
Use the Sysmac Studio to set the initial settings of the Ether-
Net/IP Function Module.
Section 7 Sysmac Studio Set-
tings for the EtherNet/IP Port on
page
7-1
• Set the BOOTP settings.
↓
2
Check operation.
• Check the event log to see if the BOOTP started.
• Check the Online device variable.
2 Specifications and Application Procedures
2-7
NX-series EtherNet/IP Unit User's Manual (W627)
2-2 EtherNet/IP Communications Procedures
