Set-up
27
Switch on the machine, see chapter 8.03 Switching the machine on / off.
Call up the threading aid function.
The workholder bar moves out of the needle area, the presser foot is lowered and the
sewing start is disengaged.
Loosen the screw 1 and insert the needle 2 into the needle bar until you feel it stop.
Adjust the needle 2 so that the long needle groove is pointing forwards and tighten the
screw 1.
Move the machine to the last position prior to the threading.
or
Move the machine to home position.
9 Set-up
Observe and comply with all regulations and information in this instruction
manual. Pay particular attention to all safety regulations!
All set-up work may only be carried out by appropriately instructed personnel.
Disconnect the machine from the electricity mains for all set-up work by
operating the main switch or by removing the mains plug!
9.01 Inserting the needle
Only use needles of the system
intended for the machine, see
chapter 3 Technical Data!
Fig. 9 - 01
1
2
