10.01 Inserting the workpiece

.01.01 Inserting the workpiece using the positioning tube

Workpieces with a striped or checked patter can be aligned with the aid of the

laser beam.

Do not look at the laser beam with or without optical aids!

Risk of retinal injuries to the eye from the concentrated light!

Single-point darts

Fig. 10 - 01

0 - 320 mm

Instruction Manual1
