Maintenance and Care
63
12.07 Checking the oil level
Switch off the machine!
Risk of injury due to accidental machine start-up!
The oil reservoir 1 must always have oil in it!
Danger of machine damage!
Check the oil level daily, add oil through the hole 2 as needed up to the line as a
maximum.
The oil tank 3 serves solely for topping up the oil reservoir 1 and not for
displaying the oil level.
Only use oil with a centre viscosity of 22.0 mm²/s at 40 °C and a density of
0.865 g/cm³ at 15 °C.
We recommend PFAFF-sewing machine oil part no. 280-1-120 144.
1
Fig. 12 - 05
2
3
