Adjustment
117
13.25.02 List of parameters
Group
Parameter
Description
Setting range
Set value
1
101 Bobbin thread monitor
0 = off, 1 = counter, 2 = sensor
0 - 2
1
102 Bobbin thread counter 0 - 999 100
103 Needle thread monitor 0 - 1
1
104 Needle thread monitor hide stitches
The number of stitches at which the needle thread
monitor is not activated when sewing is changed.
0 - 99 5
105 Needle thread / bobbin thread monitor reaction time
The sensitivity of the needle thread monitor is changed
(1= fastest reaction, max. sensitivity).
1 - 9
1
106 Process without positioning tube 0 - 1
0
107 Ironing compensation strip 0 - 1
0
108 Sewing off 0 - 1
0
109 Process without trimming 0 - 1
0
110 Sewing stop in case of a needle thread malfunction 0 - 1
0
111 Remaining piece count after activating the bobbin
thread sensor
0 - 500 20
112 Continuous run / test function 0 - 1
0
113 Wiper 2 off on left part 0 - 1
0
114 Material take-over 2 (switching in cycle) 0 - 1
0
115 Automatic program number changeover when switch-
ing to the right / left
Right = station key 0, left = station key 1
0 - 1 0
116 Additional travel in the material clamp [0.1 mm] 100 - 500 100
117 Switch on the vacuum table later 0 - 1
0
118 Tact marking laser ON - OFF
1
119 Uniform material thickness for program groups 0 - 1
0
120 Assigning the material thickness to a program group
0 = material thickness group 0 [in 0.1 mm]
1 = material thickness group 1 [in 0.1 mm]...etc.
0 - 30
0
142 Key tone 0 - 1
1
2
201 Stitch length for start backtack; (1 = standard stitch
length; 2 = 1/2 standard stitch length)
1 - 2 1
202 Stitch count for start backtack 1 - 9 2
