Sewing
40
10.02 Sewing in automatic mode
Automatic sewing mode is always called up first after switching on the machine.
O Switch the machine on.
O Switch on the suction of the positioning tube or infeed table, see chapter 7.06 Pedal.
O Insert the workpiece, see chapter 10.01 Inserting the workpiece.
O Press the start keys to start the sewing process, see chapter 7.07 Start keys.
Description of the functions on the display
Menu to input the program number
This functions opens the menu for inputting the program number, see chapter 9.07
Selecting a program number.
Input menu
This function is used to call up input mode, see chapter 11 Input.
Program selection
These functions are used to select a program from the associated program group, see also
chapter 9.08 Selecting / compiling program groups.
Material thickness
This function opens a menu to change the material thickness.
Automatic mode
This function displays the current operating mode and switches between automatic and
manual mode.
Presser foot up/down
This function is used to raise or lower the presser foot.
Right/left part
This function is used to turn the automatic switching between the right and left part on or
off. The part currently being processed is displayed.
