16 Circuit Diagrams
Reference list for the circuit diagrams
A10 CAN 1 S200 =>1
A11 CAN 2 S200 =>2
A12 CAN 3 S200 =>3
A20 Control device BS3
A22 Sewing motor control MMC 1001
A24 Needle thread monitor evaluation
A25 Needle thread monitor optics
A26 Control panel BDF-P1
A27 Laser optics
A28 Bobbin thread monitor evaluation
A29 Bobbin thread monitor optics
A30 Power supply BS3 740 VA
A31 Pulse power supply 125 VA
A32 Laser power supply 4 VA 1,1A/3,5V
A40 Stepping motor end phase
A41 SSR
B4 A10 CAN1 E4 Workholder bar up
B6 A10 CAN1 E6 Work surface forwards
B10 A10 CAN1 E10 Clamp feed unit to the right (reed)
B10A A10 CAN1 E10A Clamp feed unit in the middle (reed)
B11 A10 CAN1 E11 Clamp feed unit to the left (reed)
B12 A10 CAN1 E12 Stacker table down
B15 A10 CAN1 E15 Wiper 3 up
B50 A10 CAN1 E50 X-axis home position
B51 A10 CAN1 E51 Y-axis home position
B52 A10 CAN1 E52 Needle thread malfunction (optics)
B53 A10 CAN1 E53 Bobbin thread malfunction (optics)
B54 A10 CAN1 E54 Material in clamp (photo cell)
B18 A11 CAN2 E18 Material take-over 1 open
B19 A11 CAN2 E19 Material take-over 2 open
B40 A11 CAN2 E40 Cutter up (option - ironing compensation strip)
B40U1 A11 CAN2 E40U1 Slide back (option - ironing compensation strip)
B40U2 A11 CAN2 E40U2 Slide forwards (option - ironing compensation strip)
B55 A11 CAN2 E55 Material take-over retracted
B56 A11 CAN2 E56 Material take-over closed
B57 A11 CAN2 E57 Compressed air is okay
B27U1 A12 CAN3 E27U1 Positioning tube down
B27U2 A12 CAN3 E27U2 Positioning tube up
B28 A12 CAN3 E28 Positioning tube in the middle (vertical)
B29U1 A12 CAN3 E29U1 Infeed table lift 1 back (reed)
B29U2 A12 CAN3 E29U2 Infeed table lift 1 forwards (reed)
B30U1 A12 CAN3 E30U1 Positioning tube back
B30U2 A12 CAN3 E30U2 Positioning tube forwards
B31 A12 CAN3 E31 Positioning tube in the middle (horizontal)
B33 A12 CAN3 E33 Needles back
B34U1 A12 CAN3 E34U1 Turn-up at back
