Pfaff 3519-5/01 - CAN Errors; Stitch Generation

129
Control
Display Description
ERROR: 401 Text file cannot be opened
ERROR: 402 Error in read text file
ERROR: 403 Error when assigning memory space for the texts
ERROR: 501 Error when opening the file "pikto.hex" or "vorlagen.hex"
ERROR: 502 No ACK from control panel
14.02.02 CAN errors
Error byte Description
bit7 End phase error (short circuit)
bit6 -
bit5 -
bit4 Receive status (wait for input object)
bit3 Transmit status (send output object)
bit2 Transmit status
bit1 Node time-out
bit0 Node active
14.02.03 Stitch generation
Display Description
1 Start backtack too large
2 Start backtack too large
3 Starting stitch condensation too large
4 Incorrect bartack type
5 Bartack length > 6 mm
11 x-coord. > xsewing area_max
12 x-coord. < xsewing area_min
13 y-coord. > ysewing area_max
14 y-coord. < ysewing area_min
15 Bartack starting point is above L2 and ARSZ < 2
