132
Control
14.03 List of inputs and outputs
14
.03.01 CAN node 1
Output Description Function Comment
OUT1 Y1 Thread trimming on Valve
OUT2 Y2 Positioning tube vacuum on Valve
OUT3 Y3 Table vacuum on Valve
OUT4 Y4 Workholder bar down Valve
OUT5 Y5 Workholder bar up Valve
OUT6 Y6 Work surface forwards Valve
OUT7 Y7 Top clamp closed Valve
OUT8 Y8 Disengage bottom clamp Valve
OUT9 Y9 Clamp coupling on Valve
OUT10 Y10 Clamp feed unit to the right Valve
OUT11 Y11 Clamp feed unit to the left Valve
OUT12 Y12 Stacker table up Valve
OUT13 Y13 Needle thread tension closed Valve
OUT14 Y14 Wiper 3 off Valve
OUT15 Y15 Wiper 3 on (upwards) Valve
OUT16 Y24 Vacuum reduction on Valve
Input Description Function
IN1 E4 Workholder bar up
IN2 frei Presser foot up
IN3 E6 Work surface forwards
IN4 E10 Clamp feed unit to the right
IN5 E10A Clamp feed unit in the middle
IN6 E11 Clamp feed unit to the left
IN7 E12 Stacker table down
IN8 E15 Wiper 3 up
IN9 E50 X-axis home position
IN10 E51 Y-axis home position
IN11 E52 Needle thread malfunction
IN12 E53 Bobbin thread malfunction
IN13 E54 Material in clamp
IN14
IN15
IN16
