Pfaff 3519-5/01 User Manual

127
Control
14.02 Explanation of error messages
14
.02.01 General errors
Display Description
ERROR: 3 Error in allocating the EMS memory
ERROR: 4 C167 is not reacting
ERROR: 5 Boot file (c167boot.bin) cannot be opened
ERROR: 6 Error in flash-programming
ERROR: 7 Error when opening a file
ERROR: 8 Battery
ERROR: 9 Firmware version conflict
ERROR: 10 CAN error (reset)
ERROR: 11 CAN error (number of nodes)
ERROR: 12 Main drive communication
ERROR: OPERATING
DATA CHECK SUM
(COLD START CARRIED
OUT)
Operating data check sum
NEW OPERATING SOFT-
WARE (COLD START
CARRIED OUT)
New operating software
COLD START CARRIED
OUT
Cold start
ERROR: 101 C167 error
ERROR: 102 (#Node no.)
(status)
CAN error, status = Bit1 – node inactive,
Bit 8 – short circuit,
ERROR: 103 End phase SmX
ERROR: 104 End phase SmY
ERROR: 105 Compressed air error
ERROR: 106 Material take-over open error
ERROR: 201
(#Sewing motor error)
Sewing motor error,
see chapter 14.02.04 Sewing motor errors
ERROR: 202 (Cause) Move locked
ERROR: 203 (Cause) Move to zero point locked
ERROR: 204 (Cause) Sewing locked
ERROR: 205 (Cause) Level control function locked
ERROR: 210 Command byte of the NM interface was not free,
command could not be issued
ERROR: 211 Coordinates outside the sewing area
ERROR: 212 Stitch length too large
ERROR: 213 Zero point not found
