Pfaff 3519-5/01 User Manual

133
Control
14.03.02 CAN node 2
Output Description Function Comment
OUT1 K16 Trimmer on Contactor
OUT2 Y17 Wiper 2 off Valve
OUT3 Y23 Wiper 1 off Valve
OUT4 bobres Reset for bobbin thread monitor
(active low)
Dig. signal
OUT5 Y18 Material take-over 1 closed Valve
OUT6 Y19 Material take-over 2 closed Valve
OUT7 Y20 Thread catcher back, engage station-
ary knife
Valve
OUT8 Y21 Engage thread catcher Valve
OUT9 Y22 Turn-up limit on Valve
OUT10 Y40 Cutter down (ironing compensation
strip) *** option ***
Valve
OUT11 Y41 Slide back (ironing compensation
strip)
*** option ***
Valve
OUT12 Y42 Slide up (ironing compensation strip)
*** option ***
Valve
OUT13 Y43 Air blast (ironing compensation strip)
*** option ***
Valve
OUT14 H13_14 Lamp double start keys Lamps
OUT15 laser Marking laser on Dig. signal
OUT16
Input Description Function
IN1 E18 Material take-over 1 open
IN2 E19 Material take-over 2 open
IN3 E40 Cutter up (ironing compensation strip) *** option ***
IN4 E41U1 Slide back (ironing compensation strip) *** option ***
IN5 E41U2 Slide forward (ironing compensation strip) *** option ***
IN6
IN7 E55 Material take-over retracted
IN8 E56 Material take-over closed
IN9 E57 Compressed air is okay
IN10 E58 Vacuum foot switch
IN11 E59 Key switch
IN12 E60 Double start key 1
IN13 E61 Double start key 2
IN14
IN15
IN16
