B34U2 A12 CAN3 E34U2 Turn-up at front
B36 A12 CAN3 E36 Spreader back
B38 A12 CAN3 E38 Workholder bar table position
C1 Capacitor for trimming motor M5
E4 A10 CAN1 Workholder bar up
E6 A10 CAN1 Work surface forwards
E10 A10 CAN1 Clamp feed unit to the right
E10A A10 CAN1 Clamp feed unit in the middle
E11 A10 CAN1 Clamp feed unit to the left
E12 A10 CAN1 Stacker table down
E15 A10 CAN1 Wiper 3 up
E50 A10 CAN1 X-axis home position
E51 A10 CAN1 Y-axis home position
E52 A10 CAN1 Needle thread malfunction
E53 A10 CAN1 Bobbin thread malfunction
E54 A10 CAN1 Material in clamp
E18 A11 CAN2 Material take-over 1 open
E19 A11 CAN2 Material take-over 2 open
E40 A11 CAN2 Cutter up (option - ironing compensation strip)
E40U1 A11 CAN2 Slide back (option - ironing compensation strip)
E40U2 A11 CAN2 Slide forwards (option - ironing compensation strip)
E55 A11 CAN2 Material take-over retracted
E56 A11 CAN2 Material take-over closed
E57 A11 CAN2 Compressed air is okay
E58 A11 CAN2 Vacuum foot switch
E59 A11 CAN2 Key switch
E61 A11 CAN2 Double start key 1
E62 A11 CAN2 Double start key 2
E27U1 A12 CAN3 Positioning tube down
E27U2 A12 CAN3 Positioning tube up
E28 A12 CAN3 Positioning tube in the middle (vertical)
E29U1 A12 CAN3 Infeed table lift 1 back
E29U2 A12 CAN3 Infeed table lift 1 forwards
E30U1 A12 CAN3 Positioning tube back
E30U2 A12 CAN3 Positioning tube forwards
E31 A12 CAN3 Positioning tube in the middle (horizontal)
E33 A12 CAN3 Needles back
E34U1 A12 CAN3 Turn-up at back
E34U2 A12 CAN3 Turn-up at front
E36 A12 CAN3 Spreader back
E38 A12 CAN3 Workholder bar table position
F0 Circuit breaker 16 A
F7 M5 Trimmer motor fuse 2 A
F8 A30 Power supply fuse 10 A
F9 H11 Sewing lamp fuse 0.5 A
F10 X30 Socket fuse 10 A
H1 A30 LED => F1-2 A
H2 A30 LED => F3-2,5 A
