145
H3 A30 LED => F4-6,3 A
H4 A30 LED => F5-0,5 A
H4 A30 LED => F2-0,5 A
H10 A31 LED Pulse power supply +24V / 5A / 125 VA
H1 A40 LED Axis 1 ready
H2 A40 LED Axis 2 ready
H3 A40 LED Axis 3 ready
H4 A40 LED Axis 1 excess current
H5 A40 LED Axis 2 excess current
H6 A40 LED Axis 3 excess current
H7 A40 LED Overvoltage
H8 A40 LED Undervoltage
H9 A40 LED Excessive temperature
H15 A40 LED Mains on
H11 Sewing lamp
H12 Machine indicator light on
H13 Indicator light on double start key 1
H14 Indicator light on double start key 2
K1 Vacuum motor contactor on
K16 A41 SSR trimmer on (A11 CAN2)
M1 Sewing motor
M2 Stepping motor X-axis
M3 Stepping motor Y-axis
M4 Stepping motor B-axis (option)
M5 Trimmer motor
M6 Vacuum motor (option)
Q1 Main switch
R1 Pull-up photo cell B54
R2 Pull-up photo cell B54
S1 On switch
S2 EMERGENCY off switch
S58 A11 CAN2 E58 Vacuum foot switch
S59 A11 CAN2 E59 Key switch
S61 A11 CAN2 E61 Double start key 1
S62 A11 CAN2 E62 Double start key 2
T1 Transformer 740 VA A30 power supply3
A10 X200 CAN bus control (Dip 1 S200)
A10 X300 Outputs OUT 1 – OUT 15
A10 X400 Inputs IN 1 – IN 16
A11 X200 CAN bus control (Dip 2 S200)
A11 X300 Outputs OUT 1 – OUT 15
A11 X400 Inputs IN 1 – IN 16
A12 X200 CAN bus control (Dip 3 S200)
A12 X300 Outputs OUT 1 – OUT 15
A12 X400 Inputs IN 1 – IN 16
A20 X101 COM 2 interface
A20 X103 COM 1 interface
Circuit diagrams
