A20 X208 CAN bus
A20 X301 X-axis / motor SM 1 (M2)
A20 X302 Y-axis / motor SM 2 (M3)
A20 X303 B-axis / motor SM 3 (M4) option
A20 X400 Main drive on sewing motor M1
A20 X401 Thread monitor
A22 X2 Position sensor
A22 X3 Interface
A22 X6 Mains 230V AC
A22 X14 Sewing motor M1
A30 X1 Secondary transformer
A30 X2 Power supply BS3 x
A30 X3 Blower power supply
A30 X4 + 24V and 0V
A30 X5 + 24V and 0V
A30 X6 + 24V and 0V
A30 X7 Power supply A40 SM - end phase
A30 X8 Mains 230V AC
A30 X9 Primary transformer 230V AC
A40 X1 CAN bus connection (not used)
A40 X2 Axis 1 control
A40 X3 Axis 2 control
A40 X4 Axis 3 control
A40 X5 Bootstrap
A40 X6 Power supply + 24V and + 80V
A40 X7 Axis 1 motor – SMY M2
40 X8 Axis 2 motor – SMX M3
A40 X9 Axis 3 motor – SMB M4 (option)
A40 X10 Carriage monitoring
XWI AKZ4 Main terminal strip 400V AC and 230V AC
XWII AKZ4 Table terminal strip start
X30 Power socket 230V AC / 10A
X31 Pulse power supply 230V AC / 5A / 125VA
X33 Pulse power supply AXX +24V / 5A / 125VA
X40 PC connection RS 232 interface
X41 A26 Control panel BDF-P1
X42 A26 Control panel BDF-P1 power supply
X43 A26 Control panel BDF-P1 signal connection
X44 Rotor position sensor M1 sewing motor
X51 A50 Floppy signal connection
X52 A50 Floppy power supply
X61 Sewing motor M1
X62 Stepping motor SM X-axis M2
X63 Stepping motor SM Y-axis M3
X64 Stepping motor SM B-axis M4 (option)
X65 Trimmer motor M5
X66 Vacuum motor M6 (option)
