User’s Manual of WGS Managed Series
4.3.3 Bandwidth Utilization
The Bandwidth Utilization page displays the percentage of the total available bandwidth being used on the ports. Bandwidth
utilization statistics can be viewed using a line graph. The Bandwidth Utilization screen in Figure 4-3-7 appears.
To view the port utilization, click on the Port Management folder and then the Bandwidth Utilization link:
Figure 4-3-7 Port Bandwidth Utilization Page Screenshot
The page includes the following fields:
Object Description
• Refresh Period
This shows the period interval between last and next refresh.
Options:
2 sec
5 sec
10 sec
• IFG
Allow user to enable or disable this function
