User’s Manual of WGS Managed Series
4.15 Power over Ethernet
The WGS PoE Managed Switch Series can easily build a power central-controlled IP phone system, IP camera system and AP
group for the enterprise. For instance, cameras / APs can be easily installed around the corner in the company for surveillance
demands or build a wireless roaming environment in the office. Without the power-socket limitation, the WGS PoE Managed
Switch Series makes the installation of cameras or WLAN APs easier and more efficient.
PoE Power Budget list for WGS PoE Managed switch series
Model Name PoE Budget
144 watts
200 watts
Note
The following web screen is based on the WGS-4215-8P2S. The display of the WGS-4215-8P2S
is the same as WGS-804HPT, except PoE budget and PoE ports.
Figure 4-15-1 Power over Ethernet Screen
