User’s Manual of WGS Managed Series
: Click to transmit ICMP packets.
Be sure the target IP Address is within the same network subnet of the switch, or you have to set
the correct gateway IP address.
4.13.4 IPv6 Ping Test
This page allows you to issue ICMPv6 PING packets to troubleshoot IPv6 connectivity issues.
After you press “Apply”, 5 ICMPv6 packets are transmitted, and the sequence number and roundtrip time are displayed upon
reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs. The
ICMPv6 Ping screen in Figure 4-13-4 appears.
Figure 4-13-4 ICMPv6 Ping Page Screenshot
The page includes the following fields:
Object Description
• IP Address
The destination IPv6 Address
• Count
Number of echo requests to send
• Interval (in sec)
Send interval for each ICMP packet
• Size (in bytes)
The payload size of the ICMP packet. Values range from 8bytes to 5120bytes
• Ping Results
Display the current ping result
Buttons
: Click to transmit ICMPv6 packets
