Planet WGS-4215-T User Manual

User’s Manual of WGS Managed Series
172
4.6.8 STP Statistics
This page displays STP statistics. The STP statistics screen in Figure 4-6-17 appears.
Figure 4-6-17 STP Statistics Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical STP port
• Configuration BPDUs Received
Display the current configuration BPDUs received
• TCN BPDUs Received
Display the current TCN BPDUs received
• MSTP BPDUs Received
Display the current MSTP BPDUs received
• Configuration BPDUs
Transmitted
Display the configuration BPDUs transmitted
• TCN BPDUs Transmitted
Display the current TCN BPDUs transmitted
• MSTP BPDUs Transmitted
Display the current BPDUs transmitted
