User’s Manual of WGS Managed Series
4.4.2 LAG Management
This page is used to configure the LAG management. The LAG Management screens in Figure 4-4-4 & Figure 4-4-5 appear.
Figure 4-4-4 LAG Management Page Screenshot
The page includes the following fields:
Object Description
• LAG
Select LAG number from this drop-down list
• Name
Indicates each LAG name
• Type
Indicates the trunk type
Static: Force aggregated selected ports to be a trunk group.
LACP: LACP LAG negotiate Aggregated Port links with other LACP ports located
on a different device. If the other device ports are also LACP ports, the devices
establish a LAG between them.
• Ports
Select port number from this drop-down list to establish Link Aggregation
Figure 4-4-5 LAG Management Information Page Screenshot
