User’s Manual of WGS Managed Series
262
4.9.7.10 Option82 Circuit-ID Setting
Set creation method for option82, users can define the parameters of circuit-id suboption by themselves. Option82 Circuit-ID
Setting screens in Figure 4-9-47 & Figure 4-9-48 appear.
Figure 4-9-47 Option82 Port Circuit-ID Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port from this drop-down list
• VLAN
Indicates the ID of this particular VLAN
• Circuit ID
Set the option1 (Circuit ID) content of option 82 added by DHCP request packets
Buttons
: Click to apply changes.
Figure 4-9-48 Option82 Port Circuit-ID Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
Display the current port
• VLAN
Display the current VLAN
• Circuit ID
Display the current circuit ID
