User’s Manual of WGS Managed Series
4.16.4 Upgrade Manager
This function allows reloading of the current image or configuration of the Managed Switch to the local management station. The
Upgrade Manager screen in Figure 4-16-4 appears.
Figure 4-16-4 Upgrade Manager Page Screenshot
The page includes the following fields:
Object Description
• Upgrade Method
Select upgrade method from this drop-down list.
• Server IP
Fill in your TFTP server IP address.
• File Name
The name of firmware image or configuration.
• Upgrade Type
Select upgrade type.
• Image
Select active or backup image.
Buttons
: Click to upgrade image or configuration.
