User’s Manual of WGS Managed Series
182
Buttons
: Click to add IGMP router port entry.
Figure 4-7-13 IGMP Static Groups Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID
• Group IP Address
Display the current group IP address
• Member Ports
Display the current member ports
• Modify
Click to edit parameter
4.7.2.4 IGMP Group Table
This page provides Multicast Database. The IGMP Group Table screen in Figure 4-7-14 appears.
Figure 4-7-14 IGMP Group Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VID
• Group IP Address
Display multicast IP address for a specific multicast service
• Member Port
Display the current member port
• Type
Member types displayed include Static or Dynamic, depending on selected
options
• Life(Sec)
Display the current life
