User’s Manual of WGS Managed Series
272
4.9.9.2 Binding Table
The IP Source Guard Static Binding Entry and Table Status screens in Figure 4-9-60 & Figure 4-9-61 appear.
Figure 4-9-60 IP Source Guard Static Binding Entry Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port from this drop-down list
• VLAN ID
Indicates the ID of this particular VLAN
• MAC Address
Sourcing MAC address is allowed
• IP Address
Sourcing IP address is allowed
Buttons
: Click to add authentication list
Figure 4-9-61 IP Source Guard Binding Table Status Page Screenshot
The page includes the following fields:
Object Description
• Port
Display the current port
• VLAN ID
Display the current VLAN
• MAC Address
Display the current MAC address
• IP Address
Display the current IP Address
• Type
Display the current entry type
• Lease Time
Display the current lease time
• Action
Click to delete IP source guard binding table status entry
