User’s Manual of WGS Managed Series
4.11.4 Dynamic Learned
Dynamic MAC Table
Dynamic Learned MAC Table is shown on this page. The MAC Table is sorted first by VLAN ID and then by MAC address. The
Dynamic Learned screens in Figure 4-11-7 & Figure 4-11-8 appear.
Figure 4-11-7 Dynamic Learned Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port from this drop-down list
• VLAN
Select VLAN from this drop-down list
• MAC Address
Physical address associated with this interface
Buttons
: Refreshes the displayed table starting from the "Start from MAC address" and "VLAN" input fields
: Flushes all dynamic entries
Figure 4-11-8 MAC Address Information Page Screenshot
