Planet WGS-4215-T User Manual

User’s Manual of WGS Managed Series
353
4.16.5 Dual Image
This page provides information about the active and backup firmware images in the device, and allows you to revert to the
backup image. The web page displays two tables with information about the active and backup firmware images. The Dual
Image Configuration and Information screens in Figure 4-16-5 & Figure 4-16-6 appear.
Figure 4-15-5: Dual Image Configuration Page Screenshot
The page includes the following fields:
Object Description
• Active Image
Select the active or backup image
Buttons
: Click to apply active image.
Figure 4-16-6: Dual Image Information Page Screenshot
The page includes the following fields:
Object Description
• Flash Partition
Display the current flash partition
• Image Name
Display the current image name
• Image Size
Display the current image size
• Created Time
Display the created time
