User’s Manual of WGS Managed Series
180
• Last Member Query count
Display the current last member query count
• Last Member Query
Interval (sec)
Display the current last member query interval
• Immediate Leave
Display the current immediate leave
• Modify
Click to edit parameter
4.7.2.2 IGMP Querier Setting
This page provides IGMP Querier Setting. The IGMP Querier Setting screens in Figure 4-7-10 & Figure 4-7-11 appear.
Figure 4-7-10 IGMP VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID from this drop-down list.
• Querier State
Enable or disable the querier state.
The default value is "Disabled".
• Querier Version
Sets the querier version for compatibility with other devices on the network.
Version: 2 or 3;
Default: 2
Buttons
: Click to apply changes.
Figure 4-7-11 IGMP Querier Status Page Screenshot
