User’s Manual of WGS Managed Series
20
1.5 Product Specifications
WGS-804HPT / WGS-4215-8P2S
Product WGS-804HPT WGS-4215-8P2S WGS-4215-16P2S
Hardware Specifications
Copper Ports
8-Port 10/100/1000BASE-T
RJ45 auto-MDI/MDI-X ports
SFP/mini-GBIC Slots ---
2 x 100/1000BASE-X SFP interfaces
Supports 100/1000Mbps dual mode and DDM
PoE Inject Port
4-
Port with 802.3af / 802.3at
PoE injector function (Port-
1
to Port-4)
8-Port with 802.3af /
802.3at PoE injector
function (Port-1 to Port-8)
16-Port with 802.3af /
802.3at PoE injector
function (Port-1 to Port-8)
Switch Architecture Store-and-Forward
Switch Fabric
16Gbps/non-blocking 20Gbps/non-blocking 36Gbps/non-blocking
Switch Throughput@64 bytes 11.9Mpps @64 bytes 14.8Mpps @64 bytes 26.78Mpps @64 bytes
MAC Address Table 8K entries
Shared Data Buffer 4.1 megabits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame 10 Kbytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory default
LED
Power LED Power (Green) Power (Green)
PoE Port
PoE-in-Use (Amber)
LNK/ACT (Green)
PoE-in-Use (Amber)
LNK/ACT (Green)
PoE-in-Use (Amber)
LNK/ACT (Green)
PoE Power
Usage LED
30W, 60W, 90W, 120W
(Green)
N/A
60W, 120W, 180W, 240W
(Amber)
LAN Port
10/100/1000BASE-TX Port
(Port-5 to Port-8):
- 1000 (Green)
- LNK/ACT (Green)
N/A N/A
Fiber Port N/A
1000 LNK/ACT (Green)
100 LNK/ACT (Amber)
Connector
 Removable 3-pin terminal block for power input
- Pin 1/2 for Power (Pin 1: V+ / Pin 2: V-)
- Pin 3 for earth ground
 DC power jack with 2.1mm central pole
Power Requirements
48~56V DC, 3A (max.)
48~56V DC, 5A (max.)
Note
: The two power input
interfaces don’t support
power redundant function.
48~56V DC, 5.8A (max.)
Note
: The two power input
interfaces don’t support
power redundant function.
