User’s Manual of WGS Managed Series
4.2.7.3 SNMP View
Configure SNMPv3 view table on this page. The entry index keys are View Name and OID Subtree. The SNMPv3 View Table
Setting screens in Figure 4-2-23 and Figure 4-2-24 appear.
Figure 4-2-23 SNMPv3 View Table Setting Page Screenshot
The page includes the following fields:
Object Description
• View Name
A string identifying the view name that this entry should belong to.
The allowed string length is 1 to 16.
• Subtree OID
The OID defining the root of the subtree to add to the named view.
The allowed string content is digital number or asterisk (*).
• Subtree OID Mask
The bitmask identifies which positions in the specified object identifier are to be
regarded as "wildcards" for the purpose of pattern-matching.
• View Type
Indicates the view type that this entry should belong to. Possible view type are:
included: An optional flag to indicate that this view subtree should be included.
excluded: An optional flag to indicate that this view subtree should be excluded.
General, if a view entry's view type is 'excluded', it should exist another view
entry in which view type is 'included' and its OID subtree oversteps the 'excluded'
view entry.
Buttons
: Click to add a new view entry.
Figure 4-2-24 SNMP View Table Status Page Screenshot
