User’s Manual of WGS Managed Series
190
4.7.4.2 MLD Static Group
The MLD Static Group configuration screens in Figure 4-7-25 & Figure 4-7-26 appear.
Figure 4-7-25 Add MLD Static Group Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Select VLAN ID from this drop-down list
• Group IP Address
The IP address for a specific multicast service
• Member Ports
Select port number from this drop-down list
Buttons
: Click to add IGMP router port entry.
Figure 4-7-26 MLD Static Groups Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID
• Group IPv6 Address
Display the current group IPv6 address
• Member Ports
Display the current member ports
• Modify
Click to edit parameter.
