User’s Manual of WGS Managed Series
4.8.2.5 DSCP Mapping
The DSCP to Queue and Queue to DSCP Mapping screens in Figure 4-8-9 & Figure 4-8-10 appear.
Figure 4-8-9 DSCP to Queue and Queue to DSCP Mapping Page Screenshot
The page includes the following fields:
Object Description
• Queue
Select Queue value from this drop-down list
• DSCP
Select DSCP value from this drop-down list
Buttons
: Click to apply changes.
To Next Page
