User’s Manual of WGS Managed Series
351
4.16.2 Reboot Switch
The Reboot page enables the device to be rebooted from a remote location. Once the Reboot button is pressed, user has to
re-login the Web interface for about 60 seconds. The Reboot Switch screen in Figure 4-16-2 appears and clicks to reboot the
system.
Figure 4-16-2 Reboot Switch Page Screenshot
4.16.3 Backup Manager
This function allows backup of the current image or configuration of the Managed Switch to the local management station. The
Backup Manager screen in Figure 4-16-3 appears.
Figure 4-16-3 Backup Manager Page Screenshot
The page includes the following fields:
Object Description
• Backup Method
Select backup method from this drop-down list.
• Server IP
Fill in your TFTP server IP address.
• Backup Type
Select backup type.
• Image
Select active or backup image.
Buttons
: Click to back up image, configuration or log.
